Tianmen Textile Machinery： To exhibit high-efficiency and energy-saving equipment







Hubei Tianmen Textile Machinery Co., Ltd. will exhibit four
types of equipment during, including high speed drawing frame
TM3807S, high speed drawing frame TM3809Y, high speed drawing
frame TMFD101l, and TM5263E ring spinning machine.
High speed drawing frame tm3807S is characterized by
delivery sliver can (dia. X height): ¢600*1,200; electronic drafting,
digital weight unevenness adjusting; electronic sliver breaking,
stable and reliable; continuous multiple empty can supply;
simple and efficient driving, lower noise, energy-saving. Keyless
joint technical gear mid-located filter box, balanced suction at both
heads, auto-cleaning filter.
High speed drawing frame TM3809Y is characterized by
double uster uqa autoleveller; delivery sliver can (dia. X height):
¢600*1,200; the designed output speed: 800m/min; two deliveries
are separate, drafting and driving can achieve optimum results as
single delivery; innovative oscillating upper cleaning device is for
cleaning rubber cots as well as radiating heat; constant strength
tensioning; drafting section with patented lighting device; fixed
greasing positions on the headstock and tailstock are to prevent
from contamination of grease; pneumatic end-forming.
High speed drawing frame TMFD101l is characterized by
single delivery high speed autoleveller drawing frame; the output
speed: 1,000m/min.; 3 over 3 double zone curvilinear draft system
with pressure bar and guiding top roller; different operating covers
are separate, easy to operate; digital synchronous technology,
high driving control accuracy; low rotational inertial design, rapid
dynamic response, precise movement control; automatic endforming,
automatic filter cleaning, automatic loading and unloading
etc.; Improve the automation of machine.
TM5263E ring spinning machine is characterized by brandnew
high speed, efficient, energy-saving and digital ring spinning
machine with auto doffing; the maximum spindles of single headstock
is up to 1,632; actual speed of spinning is up to 2,2000 r/m;
the integral frame, the new cross section; the intelligent electronic
lift; the intelligent electronic draft; the intelligent doffing and automatic
bobbin feeding; double-head suction and new energy-saving
compact spinning etc.; save energy up to above 20%; new innovative
efficient drafting system; with single-spindle detection and
spindle with yarn gripper; can be combined with roving machine
and winding machine.
